Product

Overview

The indoor Enterprise Small Cell supports a new Citizens Broadband Radio Service (CBRS) for shared wireless broadband use of the 3550-3700 MHz band. WINNF SAS (Spectrum Access System) Specification compliance Rel-9 compliance, Rel-10 compliance on S1 and X2 Inter RAT HO (GSM, GERAN, WCDMA with PS) Inter RAT CSFB and redirection support (GSM, GERAN, WCDMA, TD-SCDMA) Semi Persistent Scheduling (SPS) for VoLTE MME Selection (S1 Flex) Air sniffing synchronization DL ACK/NACK Bundling Mode Automatic Neighbor Relation (ANR) Commercial Mobile Alert System (CMAS) Earthquake and Tsunami Warning System (ETWS) Long and Short DRX support TR-069, TR-196 , and Sercomm HeMS support ICIC support SuperSONTM Support Support up to 32 users for LTE users Data offload & 4G coverage improvement Automatic switch to external antennae when they are attached. CBRS market

Parameter

Maximum RF Tx Power of 24dBm per path (conducted)
2 x 2 MIMO support
2 internal antennae & 2 external antennae SMA connector
LTE operating: CBRS band (3550MHz - 3770MHz) or LTE band 42&43.
Listening band: CBRS band & band 41.
Internal antennae gain: 2.5dbi
GPS external SMA connector
Four LEDs
One Reset button
