Product

Overview

Enterprise indoor TDD-LTE Small Cell Rel-9 compliance, Rel-10 compliance on S1 and X2 Inter RAT HO (GSM, GERAN, WCDMA with PS) Inter RAT CSFB and redirection support (GSM, GERAN, WCDMA, TD-SCDMA) Semi Persistent Scheduling (SPS) for VoLTE MME Selection (S1 Flex) Air sniffing synchronization DL ACK/NACK Bundling Mode Automatic Neighbor Relation (ANR) Commercial Mobile Alert System (CMAS) Earthquake and Tsunami Warning System (ETWS) Long and Short DRX support TR-069, TR-196 , and Sercomm HeMS support ICIC support SuperSONTM Support Support up to 32 users for LTE users Data offload & 4G coverage improvement Automatic switch to external antennae when they are attached. LWA support * Enterprise

Parameter

Maximum RF Tx Power of 24dBm
2 x 2 MIMO support
2 internal antennae & 2 external antennae SMA connector
LTE operating: band 40 (2300MHz - 2370MHz)
Internal antennae gain: 2.5dbi
GPS external SMA connector
Five LEDs
One Reset button
SIM card slot
