Product

Overview

Enterprise indoor dual mode Small Cell Rel-9 compliance, Rel-10 compliance on S1 and X2 Inter RAT HO (GSM, GERAN, WCDMA with PS) Inter RAT CSFB and redirection support (GSM, GERAN, WCDMA, TD-SCDMA) Semi Persistent Scheduling (SPS) for VoLTE MME Selection (S1 Flex) Air sniffing synchronization DL ACK/NACK Bundling Mode Automatic Neighbor Relation (ANR) Commercial Mobile Alert System (CMAS) Earthquake and Tsunami Warning System (ETWS) Long and Short DRX support TR-069, TR-196 , and Sercomm HeMS support ICIC support SuperSONTM Support TD-LTE & TD-SCDMA dual mode small cell Support up to 32 users for LTE users & 16 calls for TD-SCDMA at the same time Data offload & 3G /4G coverage improvement SMS machine support Mobile extension support 3G/4G/WiFi can be managed at the same time by one management server Enterprise

Parameter

Maximum total RF Tx Power: 24dBm per mode
TD-LTE/TD-SCDMA antennae: External or Internal antennae
One WAN Ethernet (10/100/1000 Base-T) port
One LAN (10/100/1000 Base-T) port
Four LEDs (Power, 3G, 4G, WiFi)
One Reset button
One SIM card slot
WiFi (optional)
