Winners of GTI Awards 2020
Report in Collaboration with the GSMA Highlights Best Practice from National 5G Plans
After comprehensive evaluation on contribution to 4G evolution5G development , a total of 4 operators , 7 industrial partners3 individuals across terminal, chipsets, network infrastructures, test systemsverticals have stood outwon GTI Awards.
Innovative Breakthrough in Mobile Technology Award
RAN Compute Products portfolio
Ericsson RAN Compute products portfolio including baseband product familiesradio families, together with Ericsson Spectrum Sharing (ESS) technologysolution, enables operators a smooth migration to NR in LTE bandsprovides network wide 5G coverage. It supports 4G/5G dual standard basebandradio processing based on common digitalradio platform. Operators could just turn on 5G via software upgrade in the current radio base station sites. Ericsson cooperates with CMCC with this technology in field trial in Band 41will pave the way to get high efficient spectrum usage to enable load balance between TD-LTE5G NR network.
Balong 5000 is an advanced 7nm multi-mode 5G modem chipset that supports 2G/3G/4G/5G networks on a single chip. It also supports Sub6GHz 200MHz@2CC, 3GPP NR Band N41/77/78/79, NSA&SA network architectureHPUE@N41 UL 2Tx. Balong 5000 achieves world’s fastest download rate of 6.4Gbps in the millimeter wave (mmWave) frequency bands4.6Gbps in the Sub6GHz frequency bands. Also Balong 5000 is the world’s first 7nm multi-mode 5G modem chipsetsupport NSA&SA in single chipset.
With leading 5G speed, Balong 5000 brings best communication experience for all scenarios. It explored how to provide stablesmooth communication experiences in all scenarios, such as high-speed railways, subways, highways,dense business districts. Balong 5000 has flexible network architecture that supports NSA&SA in single chipset, meeting various 5G deployment scenarios of operatorsaccelerates 5G commercial process,is the world’s first full spectrum access to TDD&FDD band. Meanwhile, Balong 5000 supports Sub6GHz 200MHz@2CC CA large bandwidth, providing users with higher downloadupload rates. In the first quarter of 2019, the CPE based on Balong 5000 started to join CMCC 5G trial test promoted the maturity of 5G industry.
E7515B Network Emulation Solution
Keysight’s 5G Network Emulation Solutions, which are widely adopted across the mobile ecosystemallow users to cost-effectively validate multi-radio access technology (RAT) designs on a single platform, are built on the E7515B UXM 5G Wireless Test Platform – a highly-integrated signaling test platform with multi-format stack support, rich processing powerabundant RF resources. The solutions spanconnect the entire device workflow from R&Ddesign validation, to conformance verification, carrier acceptancemanufacturing. The integrated software-centric approach, with a common scripting engine, 5G stackadvanced analysis tools allows users to eliminate disconnected workflows across the device ecosystembetween teams to achieve more cost-efficient test methods. Exploit a high level of flexibility control to fast-track test case creationgain deeper insights from your analysis processes.
Optus is the only operator in Australia to currently have access to both 2300MHz3500MHz spectrum in Australian capital cities. Late last year Optus successfully established an end-to-end 5G data call over its 2300MHz spectrum in partnership with Ericsson. Optus has already launched 5G Fixed Wireless Access (FWA) Mobility in areas of Australia in the 3500 MHz band. The Dual Band Massive MIMO AAS introduced in Optus supports n78B40/n40. The antenna is a major step forward for Massive MIMO technology by supporting two bands in one AAS. The consolidation of two bandsone AAS significantly improves the deploy-ability of 2300MHz band as the second 5G mid band with its compact designimproved aesthetics compared to two units of AAS. The Optus solution has displayed innovation via the consolidation of two TDD mid bands within one Advance Antenna System package with new design techniques to ensure sufficient antenna isolation. Consolidation of two TDD mid bandsone AAS allows for swift deployment of a second 5G mid band to further improve 5G mid band coveragepotentially more than double the speed of Optus’ 5G service. The Dual Band Massive MIMO AAS’s compact design compared to two units of single band Massive MIMO AAS will lead to significant improvement in how we roll out our 5G network helping to accelerate the deployment of a second 5G mid band to improve customer experience in terms of both coverage capacity.
Fusion 5G chipset solution
Qorvo’s Fusion 5G chipset solution is a ground-breaking innovation in RF chipsets enabling compact, high-performance 5G functionality while balancing cost of implementation to support fastbroad roll-out of the new standard. Qorvo’s Fusion 5G chipset consists of the QM77040 mid-high band PA module with integrated duplexers (PAMiD), the QM77032 low-band PAMiD, QM75041 n41 PA module with integrated filtering (PAMiF), QM78200 n77/78 PA module with filteringLNA integrated (L-PAMiF),QM78201 n79 (L-PAMiF).
The QM77040 MHB PAMiD provides primary transmitreceives function for 4G/5G bands between 1.72.7 GHz. It supports critical n1n41 bands with excellent linearity under complex modulationbandwidths as high as 100 MHz as well as high power output necessary in early network phases. The QM77032 provides primary transmitreceive function for 4G bands between 600 MHz1 GHzimportant legacy 2G functionality in all necessary bands. The QM75041 provides key primary transmitreceive function for n41 in support of both EN-DCfull SA operation including dual 5G uplink. The QM78200QM78201 provide primary transmitreceive function for new 5G bands n77/78n79 respectively.
Innovative Mobile Service and Application Award
5G FWA Home Broadband solutionservice
Optus is proud to provide one of the first 5G Fixed Wireless Access production solutions globally, offering high-speed wireless broadband access to homessmall businesses in Optus 5G coverage areas. Our competitively priced 5G Home Broadband offers a 50Mbps minimum speed guaranteecustomer feedback to date has been incredibly positive with average speeds in excess of 160Mbps during peak times, with peak speeds close to 400Mbps. More than 190,000 households are currently eligible for Optus’ 5G FWA service. Using the Nokia FastMile 5G Gateway, the solution comprises a single, high-gain indoor device that connects wirelessly to the mobile network. It supports both 5G4G so that customers can experience the best possible in-premise WiFi service - by utilizing the best quality signals received. The plug-and-play solution is quickeasy to install without the need for appointmentstruck rolls. The device uses light-emitting diodes (LEDs) to help customers identify the right location in their premises to achieve the best wireless broadband performance. Additionally, to help customers easily set up the device at home Optus developed the Optus@Home app which assists customers in selecting the best location to set up their new device in their home. Being the first communications service provider in Australia to introduce 5G FWA commercially, we collaborated with Nokia in February 2019 to conduct the one of the world’s first live 5G FWA network trials using the FastMile 5G Gateway (device) for residential customers in Australia. The Optus 5G “Home Broadband” service was then commercially launched in November 2019. The FastMile 5G Gateway maximizes spectral assets with the industry’s highest gain (11dBi) antenna to deliver the best available in-premise wireless broadband performance. When compared to traditional solutions, the 5G Gateway delivers up to twice the indoor coverage, three times the downlink capacity five times the uplink capacity. The unique, self-aligning, directive antenna helps avoid WiFi interference from other devices in the premises. This high performancehassle-free 5G Home Broadband service plays a key role in enabling our customers to receive a 5G video experience that is unparalleled. It also provides home officesmall business customers with a higher quality broadband experience enabling enhanced applications - delivering increased productivitya superior user experience.
The Hajj Digital Bracelet system
Motivated by Saudi vision 2030guided by its pioneering “DARE” Strategy, STC is committed to maintaining its lead in the digital transformation race. By implementing a digital solution for the Hajj Umrah, STC is capitalizing on newinnovative IoT capabilitiesfocusing on utilizing its technical capabilitiesresources. The “The Hajj Digital Bracelet system” encompasses multiple solutions, seamlessly integrated to give a better hajj experience. The system was customizedused on STC’s own “IoT platform”. Subsequently, with persistent effort, it was possible to receive readings from the bracelet. This includes information such as: Heartbeats, battery level, location, etc. The collected data was subsequently used to create a solution where we could monitorprovide the appropriate support. Furthermore, STC developed a mobile application with one of its IT partners that allows the user to simply scan his/her watch, using a smartphone with NFC reading capability. This information enabled the user to display personal datagroupcompanions’ current locationhow to find them.
Location-based Smart Deployment Digital Service
Turkcell is rapidly expanding its FWA service – “Superbox” – with one key strategy from a network point of view: Maximizing the return of investment by increasing overall network utilization. To achieve this goal, a “Location-based Smart Deployment Digital Service” has been developed. It is a unique end-to-end solution, which is based on location-based analytics of network data, also site measurements performed over a Mobile application. Smart Deployment Digital Service caused $34M additional revenue by utilizing network where the cells are under-utilized, thus increasing network efficiency without any additional investment. Turkcell has been achieving big success with Superbox creating new marketgaining from other ISP DSL customers to Superbox. The ARPU of the Superbox is nearly 2 times more than Fiber-DSL ARPU. Superbox has already reached 350K customers. Smart Deployment Digital Service has played a big positive role behind this successcustomer satisfaction. The solution is flexible customizable to adapt the requirements of different services. It can also be transformed to cover new technologies like 5G.
5G smart retail application
Suning is the one of the largest onlineoffline retailers in China. SuningZTE Jointly Exploring New Trends in the Retail Industry in the 5G Era. In 2019, we have cooperated with China Mobile to provide E2E 5G + smart retail solutions for Suning e-commerceSuning logistics to provide more professional solutions to solve the problems in O2O Retail industry. We have completed the intelligent managementservice construction tasks of digital stores based on 5GMEC, completed the intelligent managementservice upgrading of Suning store,promoted the digital transformation of store "consumers、goodsstore "; 5G unmanned delivery vehicle used high-resolution camerassensors to automatically avoid obstaclespedestrians which plan their paths solving the problems of high labor costslow user privacy in the logistics industry. In the 5G logisticswarehousing phase, plan transportation lines freely to improve sorting efficiency.5G technology is used to provide navigation through laser + visual SLAM to avoid obstaclesChange the way that AGVUnmanned forklift relies on QR code navigation in the current phase. The 5G technology improves the sorting efficiency of the logistics warehouse by 60%the flexibility by 100%. It solves the problem of high manpower cost. A store no longer relies on manual delivery. A 5G drone is equivalent to 2 express dispatchers. It is estimated that a national small store in Suning can save over 10 million CNY of expenditure a month.
Market Development Award
Airtel is in its twenty fifth year of operations. From a small single circle company it was in 1995 to world’s third largest operator in 2015 the journey has been eventful. There have been path breaking shifts from the classical telco operating model, be it outsourcing its network to the partners, pioneering infrastructure sharing, creating passive infrastructure business, which have shapedimpacted the industry in a way no other company has been able to. Airtel has always collaborated with leading network solution provider to pioneer new technology in India. Airtel is leading the industry in evolution of LTE TDD towards 5G, with key highlights as follows: Development & deployment of ducting feature in TDD networks, to ensure minimum impact to customer experience & network capacity. Airtel developed the feature with all four network partnershas deployed this at scale in Indian network spanning more than 120K TDD sites. Airtel worked with all four OEMs to develop D-SON based feature in eNB to mitigate ducting impact. This feature is based on artificial intelligence in the eNB by which they are able to detect presence of ducting across clustersidentify aggressor cells which are contributing to ducting in the network. The feature has helped in improving user throughput up to 20%, increasing payload by 10%reducing customer complaints during non-ducting period (where earlier the site still used to work on SSF5) Stretching limit of spectral efficiency in TDD & FDD spectrum to get better capacityuser experience in market where user density per MHz of spectrum is maximum across the globe Worked with our OEM partners to optimize resource utilization across traffic (PRB)control channels (CCE) to increase spectral efficiency by 20% while maintainingimproving user experience. India’s mass scale Massive MIMO across multiple network partners Worked on building in-house ML which takes multiple parameters for massive MIMO site planning such as UE distribution, SRS-NI feedback, CQI samples, # of RRC users, payload etc. to identify optimal sites as best candidates for mMIMO deployments. Working with partner operators like CMCC to contribute ducting solution3GPP standards for TDD deployments in 4G /5G.
With Unique E2E 5G Products including RAN, Core, DevicesChipsets, Huawei now is number one in the world in 5G commercial deployments. As of December 2019, Huawei has signed 80+ global commercial 5G contracts, supported 41 of 61 commercially launched 5G networks,shipped 500,000+ 5G modules. Together with GTI, Huawei has actively promoted the 5G end-to-end maturity in terms of standard, spectrum, terminal, application developmentindustry exploration, thus to build a healthy 5G ecosystem. Since 2009 Huawei has focused on 5G middle-frequency large bandwidth strategyhas consistently reduced cost per bit. Together with GTI, Huawei has actively promoted the evolution of TDD spectrum to 5G, including C-Band, 2.6GHz,2.3GHz etc. Moreover, Huawei continues to actively participate in 5G standards development. Up to now, Huawei has contributed 3,371 essential 5G patents to ETSI, accounting for 20% of the global 5G submission count. In addition, Huawei has actively promoted the diversification of 5G terminals, supported GTI Terminal Alliance to promote the E2E maturity of 2.6G2.3G. With these industry promotion achievement throughout 2019, Huawei has helped operators from South Korea, Europe, Middle EastChina to launch their 5G Commercials services. In China, Huawei has helped China Mobile, China TelecomChina Unicom activate the world’s largest 5G network. 5G services are now live in 50 cities across the country, including Beijing, Shanghai, Guangzhou,Shenzhen. In Middle East, Huawei has helped 9 operators to deploy 5G network, mainly for FWA services where we have seen impressive growth in DOU. Across Europe, Huawei has helped 22 operators to launch 5G commercial networks, where user experiences have greatly been improved. In addition, Huawei’s advanced technology provides the best network performance, expanding the reachuse of mobile technology. For Consumer, Huawei has helped operators to provide consumers with 5G average single-user rate around 500 Mbpspeak-rate up to 1.1Gbps, ranking first compared with competing carriers, over 20 times of improvement compared with 4G average rate 20Mbps. In addition, Huawei’s 5G Massive-MIMO enabled VR/AR8K high definition watching experiences, offering gamers ultimate experience. For example, in LG U+ network, the arrival of optimized 5G in operators’ networks has led to a surge in AR/VR users from thousands to 500,000+. The average monthly data usage has risen from 9GB to 70GB. For Household, Huawei supplied Sunrise, Rain, 3 Kuwaitmore carrier’s 5G FWA deployment, which will connect the unconnectedenhance the penetration rate of home connection. For example, the penetration of fiber to home in Kuwait is only 10%. With 5G FWA, connections can be provided to 90% + householdsmost of small to medium-sized enterprises, achieving average 400Mbps, delivering IPTV, VRother experiences. For Industry, Huawei continues its active participation in industry alliances including: ETSI, CCSA, GSA, 5GACIA, 5GAA, etc. so that 5G can better serve the industrial digital transformation.
Kevin Walsh is vice president of mobile product marketing for Skyworks Solutions, Inc. He joined the company in 2009is currently responsible for the 5G mobile RF front-end (RFFE) platformsroadmaps – having been involved with every major RFFE transition from 3G to 4G,now to 5G. Since joining Skyworks, Mr. Walsh has driven to create market leading solutions supported by the industry’s most talented team of marketing, sales, designerssystem architects. Prior to joining Skyworks, Mr. Walsh has held a variety of positions in product marketing at RFMD, IBMSiemens Microelectronics. Mr. Walsh received a bachelor’s of science degree in solid state electronicsmicrowave engineering from the University of Massachusetts, Amherst,graduate work in marketing management from Worcester Polytechnic Institute. Since joining GTI, Mr. Walsh has tirelessly advocated advancing key RFFE concepts through commercialization beginning with multimode multiband LTE RFFE, TD-LTE ultra-high band modules, NB-IoT contributions,most recently dual band 5GNR n77 (n78)/n79 PAMiF modules with integrated SRS switching among many other efforts. This year, Mr. Walsh’s contributions include a research report on 5G device RF componentmmWave RF implications, as well as workshopstechnical speeches on Wi-Fi/n79 co-existence solution. Mr. Walsh is always keen to discuss what is next in the exciting field of mobile RF solutions.
Rohde & Schwarz
Mr. Xie Feng has over 15 years working experience at Rohde & Schwarz (R&S) headquarter in Munich, Germany. His area of expertise lies in the field of testmeasurement techniques for wireless communication. His current interest is focusing on the trends of the emerging Internet of things technology 5G. He holds several international patents in test & measurement area. Inside GTI organization, as co-leader for project/task, he supported times of technical demonstrationsspeeches. Inside R&S, he co-ordinates an global GTI task force to contribute to GTI technical works, workshopssummits.
Ms.Yuan Zhang has been serving as the task leader of 5G device power consumptionthe alignment between 4G5G device capability to promote the task forwardcontributed to GTIs technical workthe promotion of 4G/5G terminal industry.
About GTI Awards 2020
GTI Awards 2020 intends to recognize outstanding contributions in 4G & Evolution, 5G eMBB, M-IoT, 5G ENSBusiness & Services,encourage innovative products, solutions applications that address challenges faced by GTI operators.
